DC Motor Speed Switch Controller 6-24V 3A Controller PWM Regulator
Feature: CCMminiS DC Motor Speed Controller allows controlling direction of a DC motor using a Pulse-Width-Modulated (PWM) DC voltage with a Duty Cycle fully adjustable from 5%-100%. The motor speed controller can provide a continuous current of 3A to your DC motor or other DC load. Main technical parameters: Input supply voltage: 6V-28VDC(max) the maximum output power: 120W the maximum continuous output current :3A PWM frequency: 21kHz Duty Cycle adjustable: 5%-100% Specifications: Item size:66*32*24mm Net weight: 40g Package: 1* Reversible Motor Speed Controller Operating instruction: 1. Connect your motor (or DC load) to the motor terminals as indicated on the wiring diagram. The gray and blue wires connect the motor. 2.Connect a voltage of 6 to 28V DC to the circuit ma.
