Design and Implementation of Rectangular Patch Antenna for Tri-band Operation by
57,53 €
These antennas can be designed in a variety of shapes in order to obtain enhanced gain and bandwidth for dual band and tri-band operation. The fractional bandwidths (FB) after simulation obtain under criterion ( S_11 -10 dB) are 6.45% for GSM [890-960 MHz], 4.25% for WLAN [2.40 - 2.51 GHz], 6.89% for PCA [1850-1990 MHz], 11.42 % for WiMAX [3.35 - 3.94 GHz], 9.09% for UTMS [1920-2170 MHz] and 18.18% for WLAN [5.02 - 6.63 GHz] and peak gain 2.43 dBi at 5.36 GHz.
